1.5KW 80-6 | 100 END-FED ANTENNA (H.O.A. CHOICE)
Price range: $95.00 through $119.00
80 TO 6 METERS END-FED ANTENNA
The ULTIMAX 100 antenna is designed with the H.O.A., limited space amateur, and rapid deployment operator in mind. It provides for all-band operation from 80 to 6 meters continuously with just the use of an antenna tuner and no radials or grounding needed.
Description
80 to 6 METERS COVERAGEÂ 1500 Watts PEP SSBÂ 350 Watts MAX CW / RTTY/ DIGITAL MODES
Radiator Length – available models from 24′ up to 66′ available
Weight – varies by model
Polarization – Vertical, Horizontal, Sloped
Connector – SO-239 50 ohm
SWR < 1.3:1 or better After tuning in all bands (wide range tuner required)
Bands – from 3.0 MHz to 54 MHz (80 to 6 meters)
Radials or counterpoise – not required
Download The Instructions in PDF format below
Additional information
| Weight | N/A |
|---|---|
| Wire Length's | 24' Feet, 36' Feet, 49' Feet, 66' Feet |
9 reviews for 1.5KW 80-6 | 100 END-FED ANTENNA (H.O.A. CHOICE)
Related products
-
COUNTERPOISE SET FOR DXTREME
$24.00 Add to cart -
1.5KW+ SINGLE BAND BAZOOKAS
Price range: $49.00 through $305.00 Select options This product has multiple variants. The options may be chosen on the product page -
2KW 4:1 UNUN (PERFECT FOR VERTICALS)
$89.00 Add to cart -
5KW 1:1 DIPOLE BALUN
$87.00 Add to cart
Brian Richman –
This is an outstanding option for space restricted antenna use. I was going to put it in my attic but it is outside now in an inverted V configuration. I am in Texas and am getting QSO’s from the EU, Africa and of course all over North as well as a few from South America. I was surprised it doesn’t even have a connection for a counterpoise wire, but then if it uses the COAX sheath for that it’s Ok. I have a 1:1 UNUN on the shack end. SWR is down to 1.0:1 through my MFJ-949D tuner driven by my IC-7300 at full power both on SSB and digital modes. Nice product.
Tri Nguyen –
I bought the 66-foot version. I have it in a slope configuration: the dogbone end is on top of my chimney (about 23-25 feet high), and the transformer end slopes down to about 10 feet high. It works wonderfully well for my FT-100. I have not done any DX yet, but I’m absolutely satisfied with the performance.
David R –
I’ve had 5 of these over many years , gave 2 to friends. AN Incredible
antenna , Stealthy, Great performer on 6 or more bands with AUTO
TUNER In Icom 7300….a real space saver… Thank’s Alberto …..
John C. –
I have the Ultimax 100 66 Ft end fed wire antenna… I couldn’t be happier with it. It’s well made and the auto tuner in my Yaesu FTDX10 tunes it on all bands.
George Fazio WB3IGR –
I was skeptical about this antenna. I found out that I had issues with my USB radio to computer cable. Now that I replaced the cable this antenna works better than I could imagine on all bands that the manufacture said! I have the 49 foot model.
George Fazio WB3IGR –
This antenna works GREAT!!
Tim N –
I have had my license for 30 years but have never operated HF. After my son got his license a year ago, he talked me into getting an HF setup. I pondered the idea of putting up a vertical but I decided to try this end fed. I have used the 49′ end fed antenna as my primary HF antenna for the last year and love it. I have made contacts on all continents. I use it with a Palstar AT2K tuner and, at worst, get 1.2:1 SWR across all the bands. I have it mounted horizontally between two wooden posts with 100′ of coax. I pulled it down and used it for field day, pulling it up to a tree limb in a slant orientation, using only the tuner on my Yaesu FTDX-10, with 1.3:1 SWR or less and great success. I recently purchased the 53′ DXETREME to replace the 49′ end fed at home. I plan on using the 49′ end fed for portable/POTA operations. I would recommend this antenna to anyone.
George WB3IGR –
I have 2 of these antennas, 24 foot and 49 ft models. The 24 ft on I run on FT-8 with only 10 watts. Worked into Europe, Africa, South America and Asia with an LDG tuner
David –
I was initially hesitant about the 24′ wire antenna, especially given my HOA restrictions.
However, after a couple of months, I decided to go for it. I’m glad I did—it simply works!
The FT-710 internal tuner handles nearly every band, and I only need an external tuner for 80 meters. Overall, the 24′ Ultimax 100 has exceeded my expectations and comes 100% recommended.
